– 53 –

IC CARD function

IC CARD mode selection

In status with MODE/SEL button

pressed, IC CARD mode can be

selected.
When EXIT button

is pressed, the mode changes from IC CARD to normal mode.

Outline

The management of the setup menu using IC CARD, and system file and user file (USER1~USER5)
loading (reading from IC card)/saving (storing into IC card) can be performed.

The system file and user file (USER2-USER5) are provided with a lock mode to protect the settings.
The system file can be set by the setup menu No. 30 (MENU LOCK), and the user file, by the setup
menu No. A03 (MENU LOCK).
In the above menu, loading (reading from IC card) is executed even when the lock mode has been set.

* Usable cards are battery replaceable SRAM cards (64KB or over) of 68-pin two-piece type.

It is recommended to use Model BN-064HSR.

SYSTEM

USER1

USER2

USER3

USER4

USER5

IC CARD

Load/Save
