– 66 –
Setup menus
SYSTEM menu
(continued)
Item Setting
No.
Superimposed
No.
Superimposed Description
display display
12 SYS H 0550 –550
(HD)*1 : :
1100 0
: :
1650 550
13 V PHASE 0000 –500
(HD)*1 : :
0500 0
: :
1000 500
14 SYS SC 0000 –108
(SD)* 2 : :
0108 0
: :
0216 108
15 VO SYS 0000 –429
H (SD)* 2 : :
0429 0
: :
0858 429
16 SDI SYS 0000 –429
H (SD)* 2 : :
0429 0
: :
0858 429
17 V PHASE 0000 –190
(SD)* 2 : :
0190 0
: :
0380 190
18 SCH COAR 0000 0
(SD)* 2 0001 90
0002 180
0003 270
19 SCH FINE 0000 –32
(SD)* 2 : :
0032 0
: :
0064 32
The underline on the setting item denotes the initial setting.
* 1 : With the HD output (HD tape playback or up-conversion output)
* 2 : With the SD output (SD tape playback or down-conversion output)
This enables the system phase to be adjusted in 27ns steps.
–: The phase is advanced.
+: The phase is delayed.
If setting operation is performed, the setting value does not
return to factory (default) setting.
This enables the video system phase to be adjusted in 27ns
steps.
–: The phase is advanced.
+: The phase is delayed.
In the case of the HD up-converter output from the SD
playback tape (when the option has been installed), the video
phase is fixed.
This enables the system phase to be adjusted in a total
variable range of +/–180 degrees or more.
–: The phase is advanced.
+: The phase is delayed.
If setting operation is performed, the setting value does not
return to factory (default) setting.
This enables the video out system phase to be adjusted in
74ns steps.
–: The phase is advanced.
+: The phase is delayed.
If setting operation is performed, the setting value does not
return to factory (default) setting.
This enables the SDI OUT system phase to be adjusted in
74ns steps.
–: The phase is advanced.
+: The phase is delayed.
If setting operation is performed, the setting value does not
return to factory (default) setting.
This enables the video system phase to be adjusted in 148ns
steps.
–: The phase is advanced.
+: The phase is delayed.
In the case of the SD down-converter output from the HD
playback tape (when the option has been installed), the video
phase is fixed.
This enables the SCH phase to be adjusted in 90-degree
steps.
–: The phase is advanced.
+: The phase is delayed.
(The SC phase changes but the H phase remains
unchanged.)
This enables the SCH phase to be adjusted in a total variable
range of +/–45 degrees or more.
–: The phase is advanced.
+: The phase is delayed.
(The SC phase changes but the H phase remains
unchanged.)
