3. Configuring the DSL Router
6371-A2-GB20-20 May 2001 3-13
Figure 3-1, 1483 Routed Network Model (Standard mode) , illustrates the
1483 Routed model (Standard mode) in the network.
FUNI = Frame-based User-to-Network Interface
Figure 3-1. 1483 Routed Network Model (Standard mode)
O I
ALARMS Major Minor Fan B A POWER
IPC Hotwire
GranDSLAM
DSL
Router
Client
NSP's
Access
Device
NAP's
Core
Router
NAP's ATM
Network
Client
IP/MAC IP/1483/FUNI IP/1483/ATM
00-16802
NSP's
Access
Device
