SpectraLink 6100 MCU: Installation and Operation: SpectraLink 6000 System
Connect power
1. Connect the power plug from the AC adapter to the jack labeled
PWR
on the MCU.
Use only the provided Class II AC Adapter with output 24VDC, 1A.
For installations with more than one MCU, use an outlet strip with a
built-in power switch. This allows the MCUs to be turned on and off
together.
2. Plug the AC adapter into a 110VAC outlet or switch on the outlet
strip to apply power to the MCU.
Set switch interface type
The following steps explain how to assign a switch interface type to
the MCU. This procedure must be done on each MCU.
1. Power on the MCU with the mode switch in the
NORMAL
position.
Because the MCU does not have a switch type assigned, it will
alarm (the
ERROR
LED will flash along with
STATUS
LEDs
1
,
2
,
3
,
4
,
and
5
). This should take less than 2 minutes.
2. Power off the MCU.
3. Move the mode switch to
ADMIN
and power on the MCU. Within
15 seconds,
STATUS
LEDs
2
and
4
will light.
4. Press the
STEP
button three times.
STATUS
LEDs
1
,
2
, and
4
must be lit.
LINE
LEDs
1
through
8
(indicating an unconfigured MCU) should also be lit.
If any other combination of
LINE
LEDs is lit, then a switch type has
already been selected. Go to step 5 to pick the desired switch type.
5. Press the
DEL/ENTER
button to select the correct switch interface
type. With each press of the
DEL/ENTER
button, a different series of
LINE
LEDs will be lit. Continue to press
DEL/ENTER
until the correct
LINE
LEDs are lit. Use the following list to select the desired switch
interface.
