Four-wire connector b – Polycom SpectraLink 6100 MCU User Manual
Page 27
Run Cable for System
Line 1 RX
tip
ring
Line 2 RX
tip
ring
Line 3 RX
tip
ring
Line 4 RX
tip
ring
Line 5 RX
tip
ring
Line 6 RX
tip
ring
Line 7 RX
tip
ring
Line 8 RX
tip
ring
Line 9 RX
tip
ring
Line 10 RX
tip
ring
Line 11 RX
tip
ring
Line 12 RX
tip
ring
Line 13 RX
tip
ring
Line 14 RX
tip
ring
Line 15 RX
tip
ring
Line 16 RX
tip
ring
25 PAIR MALE
CONNECTOR
CABLE TO
MCU
CONNECTOR B
Telephone
Ports
Unused
Pairs
Note:
RX denotes
data received by
the telephone
system from Link 150
DO NOT
USE
Four-wire Connector B
PN: 1725-36097-001_G.doc
27
