Setting Bar Code Parameters
49
NOTE: If no values are set for parameters p2-p10, the default values will be
used. If you have sent a value from the host, this value is active until
you replace it or the printer is reset.
In this example the following parameters are changed on Line 10:
p1 = style (Code 128)
p2 = height (3/12 inch)
p9 = human readable font (use special font)
The semicolons are “place holders” for the parameters not being changed.
A list of the 10 parameters and their values follows.
p1
Selects the style.
Table 17. p1 Values
If p1 = Style
0 Interleaved 2/5
1 German PTT Interleaved 2 of 5
2 Matrix 2 of 5
3 Industrial 2 of 5
4 Code 3/9
5 EAN-8
6 EAN-13
7 Code 11
8 Reserved
9 Codabar a/t
10 Codabar b/n
11 Codabar c/*
12 Codabar d/e
13 UPC A
14 UPC E
