1. Introduction and Installation
11 For assistance, please visit http://www.panasonic.com/help
6 Hold the left cover release lever (
9), and then pull
open the left cover (
j).
7 Install the drum and toner unit (
l) by holding the
center handle.
L Make sure that the arrows ( m) match to install
the drum and toner unit correctly.
8 Close the left cover.
When to replace the toner cartridge and the drum
cartridge
When the display shows the following, replace the toner
cartridge.
Caution:
L During or immediately after printing,
the fuser unit (
k) gets hot. Wait until
the fuser unit cools down.
j
9
k
l
m
