51

defined in the software.

z

A private interface connects to your LAN, such as the Ethernet interface. Packets

received on a private interface are subject to a less restrictive set of protections, because

they originate within the network.

z

The term DMZ (de-militarized zone), in Internet networking terms, refers to computers

that are available for both public and in-network accesses (such as a company's public

Web server). Packets incoming on a DMZ interface -- whether from a LAN or external

source -- are subject to a level of protection that is in between those for public and private

interfaces.

Lower interface: EoA interfaces are defined in software, and then associated with lower-level

software and hardware structures (at the lowest level, they are associated with a physical port

- the WAN port). This field should reflect an interface name defined in the next lower level of

software over which the EoA interface will operate. This will be an ATM VC interface, such as

aal5-0.

Config IP Address and Net Mask: The IP address and network mask you want to assign to

the interface. If the interface will be used for bridging with your ISP and you will not be using

the device as a router on your LAN, then you do not need to specify IP information. If you

enable DHCP for this interface, then the Configured IP address will serve only as a request to

the DHCP server. The actual address that is assigned by the ISP may differ if this address is

not available.

Use DHCP: When enabled, this setting instructs the device to accept IP information assigned

dynamically by your ISP's DHCP server. If the interface will be used for bridging with your ISP

and you will not be routing data through it, leave this checkbox unselected.

Default Route: Indicates whether the ADSL/Ethernet router should use the IP address

assigned to this interface, if any, as its default route for your LAN. This can be Enable or

Disable.

Gateway Address: The external IP address that the ADSL/Ethernet router communicates with

via the EoA interface to gain access to the Internet. This is typically an ISP server.

Status: A green or red ball will display to indicate that the interface is currently up or down,

respectively. You cannot manually enable or disable the interface; a down interface may

indicate a problem with the DSL connection or the connection to the ISP's access server.

Action: Icons you can click on to edit (

) or delete ( ) the associated EoA interface.
