33
interface name is eth1 in above line.
LAN Configuration
To enable LAN traffic over the ethernet interface:
% ifconfig eth1 192.168.1.200 up
You may also need to modify the netmask and route for the interface. Refer to the manual
pages for ifconfig and route for more information. To test the LAN connection is alive by
pinging the remote side:
% ping 192.168.1.1
To disconnect the LAN interface:
% ifconfig eth1 down
5. Configure ADSL Router via HTML Interface
ADSL II+ Router supports a web-based (HTML) GUI to allow user to
configure Router setting via Web browser.
5.1 Login
1) Launch the Web browser.
2) Enter the default IP Address: http://192.168.1.1
3) Entry of the User Name and Password will be displayed. Enter the default login
User Name and Password. The default login User Name of the administrator is root ,
and the default admin login password is root .
