Panasonic AJ- E - Manual (Page 89)

7
Chapter 7 Menu description tables
89
7-3-9 KNEE/LEVEL
Item/
Data storage
Variable
range
Remarks
MASTER PED –200
:
+010
:
+200
For performing the MASTER PEDESTAL
setting.
$ MANUAL KNEE ON
OFF For setting the mode which is to be established
when the AUTO KNEE switch is at OFF. The
KNEE POINT/SLOPE setting value is active
when ON is selected.
KNEE POINT 70.0%
:
85.0%
:
107.0%
For setting the KNEE POINT position in 0.5%
steps.
KNEE SLOPE 00
:
50
:
99 (98)
For performing the KNEE width setting.
Same as KNEE OFF when set to 0.
The range of values that can be selected
using the AJ-EC3E is 00 to 98.
WHITE CLIP LVL 90%
:
105%
:
109%
For performing the WHITE CLIP LEVEL
setting.
A.KNEE POINT 80%
:
85%
:
107%
For setting the AUTO KNEE POINT position
in 0.5% steps. This item is active when the
OUTPUT/AUTO KNEE selector switch is set
to CAM.AUTO KNEE ON.
A.KNEE LVL 100
:
105
:
109
For performing the AUTO KNEE level setting.
A.KNEE
RESPONSE 1
:
4
For setting the AUTO KNEE response speed.
$ WHITE CLIP ON
OFF For selecting ON or OFF for the WHITE CLIP
function. The WHITE CLIP LVL setting value
is active when ON is selected.
7-3-11 FLARE
Item/
Data storage
Variable
range
Remarks
R FLARE 000
:
100
For performing the R FLARE setting.
G FLARE 000
:
100
For performing the G FLARE setting.
B FLARE 000
:
100
For performing the B FLARE setting.
7-3-10 GAMMA
Item/
Data storage
Variable
range
Remarks
MASTER GAMMA 0.35
:
0.45
:
0.75
For setting the MASTER GAMMA in 0.01
steps.
R GAMMA –15
:
+00
:
+15
For setting the R channel GAMMA.
B GAMMA –15
:
+00
:
+15
For setting the B channel GAMMA.
The underlining in the variable range column indicates the setting in the preset mode.
S C U F E
S C U F E
S C U F E
S C U F E
S C U F E
S C U F E
S C U F E
S C U F E
S C U F E
S U F E
S C U F E
S C U F E
S C U F E
S C U F E
S C U F E
Items with $ in front of their names are set by the PAINT
MENU SW ($) R/W menu items on the SELECT> screen.
Items without $ in front of their names are set by the PAINT
MENU LEVEL R/W menu item.
For details, refer to “7-6-2 CARD R/W SELECT.”
