Chapter 2 Parts and their functions
2
11
2
Either STEREO or MIX can be selected as the setting for the MONITOR
SELECT item by opening the
MENU page by performing a menu operation.
2-2 Audio function section (output system)
MONITOR
switch
CH1/3
Audio channel 1
Audio channel 3
MONITOR SELECT switch
CH1/2
CH3/4
ST
Stereo
2
signals of audio
channels 1 and 2
Stereo
2
signals of audio
channels 3 and 4
CH2/4
Audio channel 2
Audio channel 4
9
AUDIO OUT connector (XLR, 5-pin)
The audio signals recorded on audio channels 1 and 2 or
audio channels 3 and 4 are output from this connector.
With the AJ-SDC905
, the signals to be output
can be selected using the MONITOR SELECT
CH1/2OCH3/4 selector switch.
:
MONITOR SELECT (audio channel) CH1/2OCH3/4
selector switch
This is used to select the audio channels whose signals are
to be output to the speaker, earphone and AUDIO OUT
connector.
CH1/2 : The signals of audio channels 1 and 2 are output.
CH3/4 : The signals of audio channels 3 and 4 are output.
In addition, the channel indications for the audio level
meters appearing in the display window and viewfinder
change when this switch is operated.
;
MONITOR SELECT (audio selection)
CH1/3OSTOCH2/4 selector switch
This is used to select the audio channels whose signals are
to be output to the speaker, earphone and AUDIO OUT
connector in tandem with what is selected using the
MONITOR SELECT switch.
CH1/3 : The signals of audio channel 1 or 3 are output.
ST
: The stereo audio signals of either audio channels
1 and 2 or audio channels 3 and 4 are output.
Using a menu setting, the stereo signals can be
changed to MIX signals.
CH2/4 : The signals of audio channel 2 or 4 are output.
the AJ-SDC615
. The signals of CH1 and CH2
are the ones which are selected.
SDC615
SDC905
SDC905
<
MONITOR (volume) control
This is used to adjust the volume of the monitor speaker or
earphone.
=
ALARM (warning alarm volume adjustment)
This is used to adjust the volume of the warning alarms
from the earphones which have been connected to the
speaker > or PHONES jack ?.
The warning alarms are not audible when this control is at
its lowest setting.
>
Speaker
The EE sound during recording or the playback sound
during playback can be monitored through this speaker.
The warning alarms are output in synchronization with the
flashing or lighting of the warning lamps and warning
displays.
The sound heard from the speaker is automatically cut off
when earphones are connected to the PHONES jack ?.
?
PHONES (earphones) jack (mini jack)
This is the earphone (stereo) jack which is used to monitor
the audio signals. When earphones are connected, the
sound from the speaker is automatically cut off. The sound
which is output from the two jacks (front and rear) is the
same.
@
DC OUT (DC power supply) output socket
This normally serves as the DC 12 V output socket. A
current of approximately 1 A can be supplied.
