PANDUIT® DPoE™ Power Patch Panel User’s Guide Issue 2.2
Part Number: PN378A
8
DPoE™ Power Patch Panel Feature Benefit
Easier Installation By eliminating the need for separate
midspan patch panels and the associated
need for patch cord, in a network-ready 1RU
high package, The DPoE™ Power Patch
Panel is fast and easy to install.
INSTALLATION For DPOE24U1X, DPOE24U1XY, DPOE12U1X
and DPOE12U1XY (For DPOE24S1X and DPOE24S1XY see
Appendix 1)
The PANDUIT® DPoE™ Power Patch Panel requires a direct connection to a nominal 48VDC supply.
An individual power supply may be purchased separately from PANDUIT Corp or other vendors.
Installation instructions for the individual power supply are included with that product. PANDUIT Corp
provides multiple individual power supply options as listed below.
Table 1: Power Supplies Available from PANDUIT Corp.
PANDUIT Part Number Description
DPOEPWRB120 120 watt power brick - 48 volt output
DPOEPWRCU
Unmanaged power chassis - supports 3
rectifiers and optional Network Interface Card
(NIC)
DPOEPWRR500
500 watt rectifier for use in the DPOEPWRCU
chassis
DPOEPWRR1250
1250 watt rectifier for use in the DPOEPWRCU
chassis
CORD-A Power cord for Australia
CORD-E Power cord for Europe
CORD-S Power cord for USA
CORD-U Power cord for the U.K.
Package Contents
Each PANDUIT® DPoE™ Power Patch Panel is shipped in a box, which includes the following:
Table 2: Package Contents
Item Quantity Notes
DPoE™ Power Patch Panel 1 DPOE24U1X, DPOE24U1XY,
DPOE12U1X or DPOE12U1XY
Wiring Template Label 1 For use on the rear panel of the
DPoE™ Power Patch Panel –
Supports either EIA/TIA 568A or
568B wire positions.
