Panduit PA24849A01 - Manual

© Panduit Corp. 2005
Page: 1 of 2
HDCRT
PA24849A01
REV: 04 7-2005
FIBER OPTIC CONNECTOR REMOVAL TOOL
OPERATION INSTRUCTIONS
HDCRT
ERGONOMIC GRIPS
THUMB SCREWS FOR
EFFECTOR
REPLACEMENT
(See Page 2)
FIGURE 1
HDCRT
Fiber Optic Connector
Removal Tool
• HDCRT can be used by either right or left handed operators
• HDCRT is supplied with LC Effector assembly and is used with LC Fiber Optic
Connectors
(See Page 2 for additional kits (available separately)
WARNING: When using this tool (as with any tool) in a static sensitive area, the
operator should use an industry approved, standard grounding wrist
strap system.
EXTENDED EFFECTORS
WITH ANTI-SNAG TIPS
OPERATION
1. Figure 1 above illustrates the HDCRT Fiber Optic Connector Removal Tool
2. The open effectors allow the operator to pass over fiber optic cabling that interferes with
connector accessibility.
Website: www.panduit.com
E-mail: [email protected]
Technical Support:
888-506-5400, ext. 6914
Fax: 708-444-6993
