® DPoE™ Power Patch Panel User’s Guide

Issue 2.2

Part Number: PN378A

57

Table 17: Color-Coded Wire Positions for 802.3af-2003 Compliant Devices

Pin
Outs

EIA/TIA 568A

Pin
Outs

EIA/TIA 568B

5 WHITE/BLUE

5 WHITE/BLUE

4 BLUE

4 BLUE

1 WHITE/GREEN

1 WHITE/ORANGE

2 GREEN

2 ORANGE

3 WHITE/ORANGE

3 WHITE/GREEN

6 ORANGE

6 GREEN

7 WHITE/BROWN

7 WHITE/BROWN

8 BROWN

8 BROWN

The DPoE™ Power Patch panel supports standard IEEE 802.3af-2003 devices as well as alternate PoE
devices consistent with the Cisco legacy devices.

Table 18: Color-Coded Wire Positions for Alternate PoE Devices

Pin
Outs

EIA/TIA 568A

Pin
Outs

EIA/TIA 568B

5 WHITE/BROWN

5 WHITE/BROWN

4 BROWN

4 BROWN

1 WHITE/GREEN

1 WHITE/ORANGE

2 GREEN

2 ORANGE

3 WHITE/ORANGE

3 WHITE/GREEN

6 ORANGE

6 GREEN

7 WHITE/BLUE

7 WHITE/BLUE

8 BLUE

8 BLUE



7. For best performance, the cable pair twists should be maintained as close as possible to the point

of termination. Punchdown the conductors with a 110 Punchdown tool (PANDUIT part
no.PDT110). Record port information on the PANDUIT DPoE Power Patch Panel Installation
Worksheet (PANDUIT part no. PN377*). To ensure proper shielding, there must be approximately
1" (25.4 mm) between the cable foil or braid covered with copper tape and the punchdown
connector.

NOTE:

The DPoE™ Power Patch Panel can
terminate most 22-24 AWG solid or
stranded IWC wire with a .050”
(1.27mm) max o.d. either PVC or
Plenum rated.
