PANDUIT ® DPoE™ Power Patch Panel User’s Guide Issue 2.2
Part Number: PN378A
53
APPENDIX 1 – DPOE24S1X AND DPOE24S1XY
INSTALLATION
The PANDUIT® DPoE™ Shielded Power Patch Panel requires a direct connection to a nominal 48VDC
supply. An individual power supply may be purchased separately from PANDUIT Corp or other vendors.
Installation instructions for the individual power supply are included with that product. PANDUIT Corp
provides multiple individual power supply options as listed below.
Table 14: Power Supplies Available from PANDUIT Corp.
PANDUIT Part Number Description
DPOEPWRB120 120 watt power brick - 48 volt output
DPOEPWRCU
Unmanaged power chassis - supports 3
rectifiers and optional Network Interface Card
(NIC)
DPOEPWRR500
500 watt rectifier for use in the DPOEPWRCU
chassis
DPOEPWRR1250
1250 watt rectifier for use in the DPOEPWRCU
chassis
CORD-A Power cord for Australia
CORD-E Power cord for Europe
CORD-S Power cord for USA
CORD-U Power cord for the U.K.
Package Contents
Each PANDUIT® DPoE™ Shielded Power Patch Panel is shipped in a box that includes the following:
Table 15: Package Contents
Item Quantity Notes
DPOE24S1X or DPOE24S1XY Power Patch Panel 1 The shielded version of the
DPOE24U1X or DPOE24U1XY.
Rear shields 2 Top and bottom rear shields.
Wiring Template Label 1 For use on the rear panel of the
DPOE24S1X or DPOE24S1XY –
Supports either EIA/TIA 568A or
568B wire positions.
Quick Installation Instructions 1 PANDUIT Part Number PN404
DPOE™ Power Patch Panel Installation Worksheet 1 PANDUIT Part Number PN377
