The system and the other setup
11
94
En
4
Specify whether your subwoofer is THX Select2
certified or not.
If your subwoofer isn’t THX Select2 certified, but you still
want to switch boundary gain compensation on, select
YES here, but the effect might not work properly.
5
Select either ON or OFF for Boundary Gain
Compensation (BGC) setting.
6
When you’re finished, press RETURN.
You will return to the Manual SP Setup menu.
The Other Setup menu
The Other Setup menu is where you can make
customized settings to reflect how you are using the
receiver.
1
Press
on the remote control, then press
HOME MENU.
A Graphical User Interface (GUI) screen appears on your
TV. Use
/// and ENTER to navigate through the
screens and select menu items. Press RETURN to
confirm and exit the current menu.
2
Select ‘System Setup’ from the HOME MENU.
3
Select ‘Other Setup’, then press ENTER.
4
Select the setting you want to adjust.
If you are doing this for the first time, you may want to
adjust these settings in order:
• KURO LINK Setup – Synchronizes this receiver with
your Pioneer component supporting KURO LINK (see
KURO LINK Setup on page 64).
• Multi Ch In Setup – Specifies the optional settings for
a multi-channel input (page 94).
• ZONE Audio Setup – Specifies the volume setting
for a MULTI-ZONE setup (page 95).
• Power ON Level Setup – Specifies the volume level
set when the power is turned on (page 95).
• Volume Limit Setup – Limits the maximum volume
(page 95).
• Remote Control Mode Setup – Sets this receiver’s
remote control mode (page 96).
• Flicker Reduction – Adjusts the way the GUI screen
looks (page 96).
5
Make the adjustments necessary for each setting,
pressing RETURN to confirm after each screen.
Multi Channel Input Setup
You can adjust the level of the subwoofer for a multi-
channel input. Also, when the multi-channel input is
selected as an input function, you can display the video
images of other input functions. In the Multi Channel
Input Setup, you can assign a video input to the multi-
channel input.
1
Select ‘Multi Ch In Setup’ from the Other Setup
menu.
2
Select the ‘SW Input Gain’ setting you want.
• 0dB – Outputs sound of the subwoofer at the level
originally recorded on the source.
• +10dB – Outputs sound of the subwoofer at the level
increased by 10 dB.
A/V RECEIVER
Exit
Finish
4a6.THX Audio Setting
Loudness Plus
:
ON
SB SP Position
:
4 ft<
BGC :
OFF
THX Select2 SW :
YES
Loudness Plus
:
ON
SB SP Position
:
4 ft<
BGC :
OFF
THX Select2 SW :
YES
A/V RECEIVER
Exit
Finish
4a6.THX Audio Setting
RECEIVER
A/V RECEIVER
Exit
Return
a.Manual SP Setup
b. Input Setup
c. OSD Language
d. Other Setup
4.SystemSetup
2. Multi Ch In Setup
3. ZONE Audio Setup
4. Power ON Level Setup
5. Volume Limit Setup
6. Remote Control Mode Setup
7. Flicker Reduction Setup
1. KURO LINK Setup
4d.Other Setup
A/V RECEIVER
Exit
Return
4d.Other Setup
A/V RECEIVER
Exit
Return
3. ZONE Audio Setup
4. Power ON Level Setup
5. Volume Limit Setup
6. Remote Control Mode Setup
7. Flicker Reduction Setup
2. Multi Ch In Setup
1. KURO LINK Setup
4d2.Multi Ch In Setup
A/V RECEIVER
Exit
Finish
SW Input Gain
:
0dB
Video Input
:
DVD
