4. Monitoring the Hotwire DSL System
8000-A2-GB26-50 April 2001 4-19
DSL SN Information Screen
Use the SN Information screen to display read-only Service Node information.
Procedure
1. Follow this menu selection sequence:
Monitoring
→
SN Information (B-F)
2. The SN menu appears. The information displayed on this screen is shown in
Table 4-5, Service Node Options .
ARP Table B-D-F
Displays the current Address Resolution Protocol (ARP) cache.
Line – Sequential number of line.
IP Address – Internet Protocol Address.
MAC Address – MAC address associated with the IP address. (An incomplete can be
shown in this column for some internal entries such as the backplane.)
Min – Number of minutes since this entry was last used.
VNID – VNID between 2–4000 for DSL cards with an Ethernet Network Interface, or
2–255 for DSL cards with an ATM Network Interface (Default = none).
Flags – Various flags associated with this entry.
T PM = permanent
T PB = publish this entry (respond for other hosts)
T TR = trailers
T PX = proxy ARP (card will proxy ARP for this IP address)
T SB = subnet proxy ARP
Table 4-4. Bridge Options (4 of 4)
