4. Monitoring the Hotwire DSL System
4-16
April 2001
8000-A2-GB26-50
DSL Bridge Screens
Use the Bridge screens to display read-only system bridge information.
Procedure
To view bridge information:
1. Follow this menu selection sequence:
Monitoring
→
Bridge (B-D)
2. The Bridge menu appears. Select the submenu option as shown in
, and press Enter.
Table 4-4.
Bridge Options (1 of 4)
Card VNID Table
B-D-A
Displays information on various bridge functions.
Item – Enter the item number you wish to display from 1–32.
VNID – VNID number from 2–4000, in VNID tagged mode (Default = none in VNID
untagged mode, with only one VNID entry).
Mux Fwd – Enable = traffic forced upstream (Disable = blank).
IP Filter – Enable/Disable.
IP Scoping – Enable/Disable.
VNID Auth – Only interfaces bound to this VNID will accept packets with this VNID
number.
Domain Name – Domain name of the card. There can be up to 12 VNID addresses at a
time, with a maximum of 30 characters each.
