Pentax 330RS - Manual (Page 67)

131
Appendix
130
Appendix
Exposure Control
Metering System TTL metering. Choice of Multi-segment metering, Center-
weighted metering and Spot metering.
Exposure Modes Standard, Night Scene, Metered Manual, Movie, Multiple
Exposure.
Exposure Compensation ±2 EV (1/3 steps).
Movie Shooting time: approx. 1 sec. - 30 sec.
Shutter Programmed AE electronic lens shutter with CCD electronic
shutter.
Shutter speed: approx. 1/2000 sec. to 4 sec.
Drive Modes One shot, Continuous, Self-timer, Remote control and
Interval.
Flash Built-in series-control auto flash.
Automatic discharge under low lighting condition in auto modes.
Flash-on and flash-off modes. “Red-eye” reduction function
employs a single discharge.
White Balance Auto, Daylight, Shade, Tungsten Light, Fluorescent Light and
Manual setting.
Optical Viewfinder Actual-image zoom viewfinder with diopter adjustment from -
3 m
-1 to +1 m -1 .
LCD Monitor 1.6 inch. TFT color LCD. Field of view: 100%
LCD Functions Nine-image and 1x – 4x magnification available in Playback
mode.
Number of recordable images Approx. 250 (with the flash fired for 50 % of the shots. LCD
monitor ON)
*In accordance with Pentax photographic conditions.
Interfaces USB terminal and DC input terminal.
Power Sources Lithium-ion (rechargeable) battery allows approx. 250 shots
(with the flash fired for 50% of the shots and LCD monitor
ON) to be taken with one charge*.
Optional AC adapter is also available.
*According to tests conducted in-house by Pentax.
Maximum charge takes approximately 120 minutes.
Dimensions 92 (W) × 59 (H) × 32 (D) mm (D: max 34.5 mm)
(3.6 Ч 2.3 Ч 1.3/1.4 inches).
Weight 200 g (7.1 oz.) without battery and CF card.
235 g (8.3 oz.) including battery and CF card.
Main Specifications
Type Compact-type digital still camera with built-in zoom lens,
autofocus, auto exposure and auto flash.
Effective pixels 4.0 megapixel (430RS), 3.2 megapixel (330RS)
Sensor Total pixels – 4.13 megapixel (Optio 430RS), 3.34 megapixel
(Optio 330RS)
1/1.8 inch interline transfer CCD with a primary color filter.
Color Depth 10 bit × 3 colors.
Recorded Pixels Still – 2304 × 1712 pixels (430RS), 2240 × 1680 pixels (430RS),
2048 × 1536 pixels (330RS), 1600 × 1200 pixels,
1024 × 768 pixels, 640 × 4800 pixels
Movie – 320 × 240 pixels.
Sensitivity Auto, fixed (equivalent to ISO 100, 200 (430RS); ISO 125,
250 (330RS)).
File Formats Still – JPEG (Exif 2.2), DCF, DPOF.
Movie – AVI (Open DML Motion JPEG), 15fps.
Quality Levels “Good”, “Better”, “Best”.
Storage Media Built-in memory (approx. 11MB),
CompactFlash (CF) card Type I
Lens Pentax power zoom 7.6 mm - 22.8 mm (Equivalent to
37.5mm - 112.5 mm in 35 mm format) F2.6 - F4.8,
7 elements in 6 groups (2 dual-sided aspherical elements).
Digital Zoom 1 Ч – 2Ч.
Focusing System
Type TTL contrast detection autofocus system.
Manual focus / Infinity-landscape mode available.
Focusing Areas 7-point autofocus and spot.
Focusing Range Autofocus: Normal 0.4 m (1.31 ft) to infinity.
Macro 0.14 m (0.46 ft) to 0.5 m (1.64 ft).
Manual focus: 0.14 m (0.46 ft) to infinity.
