Solstice I12 Water Cooker Computer Service
Part #60153301
L22-306 Rev 0 13
4 To Enter Programming Level 3 (for the Technician)
With no cook timers running, displays will show one of the following displays: [HEATING]
or [READY]. Press the program key. If [PASS ----] [PASSWORD] is displayed
refer to section 2.0. After entering the store managers password, the display will show
[PROGRAM]. Right display will be blank.
Enter technicians password
Level 3 Password
using the location keys as numeric keypad for entry.
Display will show [SERVICE]. Product key indicators will
illuminate to prompt operator to select a key. This section details
parameters that may be changed in Level 3 programming.
4.1 Offset Temperature Display
This adjustment allows the displayed temperature value to be offset to reflect the true center vat
temperature while reading the probe tip temperature. Default value is zero. With zero
value set, displayed values are the probe temperature.
With display showing [SERVICE] press product key 1.
Display shows [OFF nn F] [DEGREES], where “nn” is the value of the adjustment.
Negative values are preceded with a minus sign. To change this value, use the location keys for
numeric entry of a new value.
Press the key. Display will show [POSITIVE] [DEGREES].
Use the product key to scroll choices (Positive or Negative value). After selection, press the
key. Display shows [SERVICE].
Note: Computer Display Temp – Center Vat Temp = Offset (+/-). Example: Computer Display shows
185F while Center Vat Temp measures at 182F; 185F – 182F = - 3 °F. A negative offset value.
Warning: Proper equipment and expertise is required to properly adjust this value. Even small changes
may negatively effect cooking performance.
4.2 Minimum Cycle Times
With display showing [SERVICE], press product key 3.
Display shows [MIN ON:nn] [MIN ON], where “nn” is the value, in seconds, for minimum
heat pulse period. To change this value, use the location keys for numeric entry of a new
value, then press the key. Display now shows [MINOFF:nn] [MIN OFF]. The value
of nn is minimum number of seconds an off period can last.
Press the key. Display now shows [SERVICE].
