Page 47
A---23
Powerware 9315 Maintenance Bypass Module 30---160kVA
164201177 Rev. C 041500
DESCRIPTION:
DATE:
DRAWING NO:
4 of 4
SHEET:
REVISION:
A
164201177---10
LINE UP AND MATCH ARRANGMENT NOTES
080498
1
Line up and match power and control interconnection wiring from
MBM to UPS/Input Transformer cabinet is applicable for Reverse
Transfer (Single UPS module) connection only and sold separately
by Powerware Corporation.
2
Run power cables underneath the transformer.
3
External wiring is required and supplied by others.
4
The PDM cabinet is applicable IF AND ONLY IF the MBM and UPS
module outputs are 3 phase, 60Hz, 280VAC.
5
Refer to Powerware 9315 UPS module installation manual for
proper terminating lugs.
