DESCRIPTION:
DATE:
DRAWING NO:
1 of 2
INSTALLATION NOTES
SHEET:
REVISION:
C
164201177---1
041500
A---6 Powerware 9315 Maintenance Bypass Module 30-160kVA
164201177 Rev. C 041500
Table B. Circuit Breaker Requirements for
Powerware 9315
MBM 30---160 KVA , 380:380 VAC , 400:400 VAC , 415:415 VAC , 600:600 VAC ,
480:208 VAC , 600:208 VAC, 208:208 VAC, 480:480 VAC .
MBM MBM
BIB1 & BIB2 MBP & MIS
MBM
FAMILY
MBM
Model No.
V
in
/V
out
I
in
/I
out
Frame/Trip Instantaneous
Trip Range
Frame/Trip Instantaneous
Trip Range
MBM 50 MBM 50/30---48/20 480V/208V 36A/83A 100A/40A 150---1200A 250A/100A 375---3000A
MBM 50/30---48/48 480V/480V 36A/36A 100A/40A 150---1200A 100A/40A 150---1200A
MBM 50/30---60/20 600V/208V 29A/83A 100A/40A 150---1200A 250A/100A 375---3000A
30KVA
MBM 50/30---20/20 208V/208V 83A/83A 250A/100A 375---3000A 250A/100A 375---3000A
30KVA
MBM 50/30---38/38 380V/380V 45A/45A 100A/50A 150---1200A 100A/50A 150---1200A
MBM 50/30---40/40 400V/400V 45A/45A 100A/50A 150---1200A 100A/50A 150---1200A
MBM 50/30---41/41 410V/410V 45A/45A 100A/50A 150---1200A 100A/50A 150---1200A
MBM 50/40---48/20 480V/208V 48A/111A 100A/50A 150---1200A 250A/125A 375---3000A
MBM 50/40---48/48 480V/480V 48A/48A 100A/50A 150---1200A 100A/50A 150---1200A
MBM 50/40---60/20 600V/208V 38A/111A 100A/40A 150---1200A 250A/125A 375---3000A
40KVA MBM 50/40---20/20 208V/208V 111A/111A 250A/125A 375---3000A 250A/125A 375---3000A
MBM 50/40---38/38 380V/380V 60A/60A 100A/70A 150---1200A 100A/70A 150---1200A
MBM 50/40---40/40 400V/400V 60A/60A 100A/70A 150---1200A 100A/70A 150---1200A
MBM 50/40---41/41 415V/415V 60A/60A 100A/70A 150---1200A 100A/70A 150---1200A
MBM 50/50---48/20 480V/208V 60A/139A 100A/70A 150---1200A 250A/150A 375---3000A
50KVA
MBM 50/50---48/48 480V/480V 60A/60A 100A/70A 150---1200A 100A/70A 150---1200A
50KVA
MBM 50/50---60/20 600V/208V 48A/139A 100A/50A 150---1200A 250A/150A 375---3000A
MBM 50/50---20/20 208V/208V 139A/139A 250A/150A 375---3000A 250A/150A 375---3000A
MBM 80 MBM 80/50---48/20 480V/208V 60A/139A 100A/70A 150---1200A 250A/150A 375---3000A
MBM 80/50---48/48 480V/480V 60A/60A 100A/70A 150---1200A 100A/70A 150---1200A
MBM 80/50---60/20 600V/208V 48A/139A 100A/50A 150---1200A 250A/150A 375---3000A
50KVA
MBM 80/50---38/38 380V/380V 74A/74A 100A/80A 150---1200A 100A/80A 150---1200A
50KVA
MBM 80/50---40/40 400V/400V 74A/74A 100A/80A 150---1200A 100A/80A 150---1200A
MBM 80/50---41/41 415V/415V 74A/74A 100A/80A 150---1200A 100A/80A 150---1200A
MBM 80/50---20/20 208V/208V 139A/139A 250A/150A 375---3000A 250A/150A 375---3000A
MBM 80/65---48/20 480V/208V 78A/180A 100A/80A 150---1200A 250A/200A 375---3000A
MBM 80/65---48/48 480V/480V 78A/78A 100A/80A 150---1200A 100A/80A 150---1200A
MBM 80/65---60/20 600V/208V 63A/180A 100A/70A 150---1200A 250A/200A 375---3000A
65KVA MBM 80/65---38/38 380V/380V 97A/97A 250A/100A 375---3000A 250A/100A 375---3000A
MBM 80/65---40/40 400V/400V 97A/97A 250A/100A 375---3000A 250A/100A 375---3000A
MBM 80/65---41/41 415V/415V 94A/94A 250A/100A 375---3000A 250A/100A 375---3000A
MBM 80/65---20/20 208V/208V 180A/180A 250A/200A 375---3000A 250A/200A 375---3000A
NOTE: See Sheet 2 For Model Number Legend.
