A---8 Powerware 9315 Maintenance Bypass Module 30-160kVA
164201177 Rev. C 041500
Table C--1. Power Cable Terminations
With Optional BIB Without Optional BIB
Terminal
Function
Terminal Function
Size of
Presure
Terminal
Tightening
Torque
N---M
(lb---in)
Int.
Hex
Size
(In.)
Size of
Presure
Terminal
Tightening
Torque
N---M
(lb---in)
Int.
Hex
Size
(In.)
Powerware 9315
UPS Model in KVA
(see note below)
2---#6-350
kcmil
(Note 2)
31.1 (275) 3/8
1---#6-350
kcmil
(Note 3)
31.1 (275) 3/8
30---160KVA,
38/38, 48/48, 60/60
30---80KVA, 20/20
AC Input to
MBM
E1,
E2,
E3
Phase A,
Phase B,
Phase C
2---#6-350
kcmil
(Note 2)
31.1 (275) 3/8
2---#6-350
kcmil
(Note 2)
31.1 (275) 3/8
30---160KVA,
48/20, 60/20
E3 Phase C
4---#2-600
kcmil
(Note 2)
56.5 (500) 1/2
3---#3/0-400
kcmil
(Note 3)
42.4 (375) 5/16 100---160KVA, 20/20
AC Input to
UPS Bypass
(BIB breaker
BIB---2,
BIB---4,
Phase A,
Phase B,
1---#6-350
kcmil
31.1 (275) 3/8 N/A N/A N/A
30---160KVA,
38/38, 48/48, 60/60, 48/20, 60/20
30---80KVA, 20/20
(BIB breaker
Load side)
BIB---4,
BIB---6
Phase B,
Phase C 3---#3/0-400
kcmil
42.4 (375) 5/16 N/A N/A N/A 100---160KVA, 20/20
UPS Output
to MBM
(MIS breaker
MIS---1,
MIS---3,
MIS 5
Phase A,
Phase B,
Phase C
1---#6-350
kcmil
311 (275) 3/8
1---#6-350
kcmil
311 (275) 3/8
30---160KVA,
38/38, 48/48, 60/60
30---80KVA,
48/20, 60/20, 20/20
(MIS breaker
Line side)
MIS---5 Phase C
3---#3/0-400
kcmil
42.4 (375) 5/16 3---#3/0-400
kcmil
42.4 (375) 5/16
100---160KVA,
48/20, 60/20, 20/20
MBM Output
to Critical
Load
E13,
E14,
E15
Phase A,
Phase B,
Phase C
2---#6-350
kcmil
31.1 (275) 3/8
2---#6-350
kcmil
31.1 (275) 3/8
30---160KVA,
38/38, 48/48, 60/60
30---80KVA,
48/20, 60/20, 20/20
Load E15 Phase C
4---#2-600
kcmil
56.5 (500) 1/2
4---#2-600
kcmil
56.5 (500) 1/2
100---160KVA,
48/20, 60/20, 20/20
Neutral Lug E12 Neutral
12---#2-500
kcmil
56.5 (500) 1/2
12---#2-500
kcmil
56.5 (500) 1/2 30---160KVA, all voltages
Customer
Ground Lug
Ground Ground
2---#6-350
kcmil
31.1 (275) 3/8
2---#6-350
kcmil
31.1 (275) 3/8 30---160KVA, all voltages
NOTES: Model Number Legend
1. 38/38: 380VAC in---380VAC out; 48/48: 480VAC in---480VAC out; 60/60: 600VAC in---600VAC out
48/20: 480VAC in---208VAC out; 60/20: 600VAC in---208VAC out; 20/20: 208VAC in---208VAC out
2. AC input wiring is connected to input lugs E1---E3. Lugs are located on the right side of BIB breaker.
3. AC input wiring is connected directly to the line side of MBP breaker (MBP---1, MBP---3, and MBP---5).
4. AC input wiring is connected to input lugs E1---E3.
DESCRIPTION:
DATE:
DRAWING NO:
1 of 2
SHEET:
REVISION:
C 041500
164201177---1
INSTALLATION NOTES
