Powerware 30-160kVA User Manual
Page 15
11
Powerware 9315 Maintenance Bypass Module 30---160kVA
164201177 Rev. C 041500
Installing and Wiring the
Maintenance Bypass Module
When the maintenance bypass module (MBM) has been moved to its installed
location, unpacked, and inspected, it is ready for installation. This section
discusses the typical process of installing the MBM in both the line-up and match
and free-standing situations. The MBM is shown in Figure 5.
Cable Entry, Top Plan View
Cable Entry, Bottom Plan View
Cooling Air Inlets
(Front)
(Front)
Figure 5. Top, Bottom, and Front View of Maintenance Bypass Module
(30---160kVA with or without XFMR)
