DESCRIPTION:
DATE:
DRAWING NO:
2 of 2
INSTALLATION NOTES
SHEET:
REVISION:
C
164201177---1
041500
A---7 Powerware 9315 Maintenance Bypass Module 30---160kVA
164201177 Rev. C 041500
Table B. Circuit Breaker Requirements for
Powerware 9315
MBM 30---160 KVA , 380:380 VAC , 400:400 VAC , 415:415 VAC , 600:600 VAC ,
480:208 VAC , 600:208 VAC, 208:208 VAC, 480:480 VAC .
MBM MBM
BIB1 & BIB2 MBP & MIS
MBM
FAMILY
MBM
Model No.
V
in
/V
out
Ii
n
/I
out
Frame/Trip Instantaneous
Trip Range
Frame/Trip Instantaneous
Trip Range
MBM 80 MBM 80/50---48/20 480V/208V 60A/139A 100A/70A 150---1200A 250A/150A 375---3000A
MBM 80/80---48/20 480V/208V 96A/222A 100A/100A 150---1200A 250A/237A 375---3000A
MBM 80/80---48/48 480V/480V 96A/96A 100A/100A 150---1200A 100A/100A 150---1200A
80KVA
MBM 80/80---60/20 600V/208V 77A/222A 100A/80A 150---1200A 250A/237A 375---3000A
80KVA
MBM 80/80---38/38 380V/380V 115A/115A 250A/125A 375---3000A 250A/125A 375---3000A
MBM 80/80---40/40 400V/400V 115A/115A 250A/125A 375---3000A 250A/125A 375---3000A
MBM 80/80---41/41 415V/415V 115A/115A 250A/125A 375---3000A 250A/125A 375---3000A
MBM 160 MBM 80/80---20/20 208V/208V 222A/222A 250A/237A 375---3000A 250A/237A 375---3000A
MBM 160/100---48/20 480V/208V 120A/278A 250A/125A 375---3000A 600A/300A 900---7200A
MBM 160/100---48/48 480V/480V 120A/120A 250A/125A 375---3000A 250A/125A 375---3000A
MBM 160/100---60/20 600V/208V 96A/278A 250A/100A 375---3000A 600A/300A 900---7200A
100KVA
MBM 160/100---60/60 600V/600V 96A/96A 250A/100A 375---3000A 250A/100A 375---3000A
100KVA
MBM 160/100---38/38 380V/380V 146A/146A 250A/150A 375---3000A 250A/150A 375---3000A
MBM 160/100---40/40 400V/400A 146A/146A 250A/150A 375---3000A 250A/150A 375---3000A
MBM 160/100---41/41 415V/415V 146A/146A 250A/150A 375---3000A 250A/150A 375---3000A
MBM 160/100---20/20 208V/208A 278A/278A 600A/300A 900---7200A 600A/300A 900---7200A
MBM 160/130---48/20 480V/208V 156A/361A 250A/175A 375---3000A 600A/420A 900---7200A
MBM 160/130---48/48 480V/480V 156A/156A 250A/175A 375---3000A 250A/175A 375---3000A
MBM 160/130---60/20 600V/208V 125A/361A 250A/150A 375---3000A 600A/420A 900---7200A
130KVA
MBM 160/130---60/60 600V/600V 125A/125A 250A/150A 375---3000A 250A/150A 375---3000A
130KVA
MBM 160/130---38/38 380V/380V 188A/188A 250A/200A 375---3000A 250A/200A 375---3000A
MBM 160/130---40/40 400V/400V 188A/188A 250A/200A 375---3000A 250A/200A 375---3000A
MBM 160/130---41/41 415V/415V 188A/188A 250A/200A 375---3000A 250A/200A 375---3000A
MBM 160/130---20/20 208V/208V 361A/361A 600A/420A 900---7200A 600A/420A 900---7200A
MBM 160/160---48/20 480V/208V 192A/444A 250A/200A 375---3000A 600A/480A 900---7200A
MBM 160/160---48/48 480V/480V 192A/192A 250A/200A 375---3000A 250A/200A 375---3000A
MBM 160/160---60/20 600V/208V 153A/444A 250A/175A 375---3000A 600A/480A 900---7200A
160KVA
MBM 160/160---60/60 600V/600V 153A/153A 250A/175A 375---3000A 250A/175A 375---3000A
160KVA
MBM 160/160---38/38 380V/380V 231A/231A 250A/237A 375---3000A 250A/237A 375---3000A
MBM 160/160---40/40 400V/400V 231A/231A 250A/237A 375---3000A 250A/237A 375---3000A
MBM 160/160---41/41 415V/415V 231A/231A 250A/237A 375---3000A 250A/237A 375---3000A
MBM 160/160---20/20 208V/208V 444A/444A 600A/480A 600A/480A 900---7200A
NOTE: Model Number Legend
1. MBM 50/30---20/20 means MBM cabinet,
Family 50, 208V (input) and 208V (output),
model 30 (30kVA).
2. All breakers are 100% UL rated with
Interrupting Capacity (IC) of 65kAIC@480VAC.
