AV3,AVM3/AVT3,AVL3
ORDERING INFORMATION
1.FS switches
2.FS-T switches
* Gold-clad triple layer contact
Type of
switch
Terminals Actuators Contacts
1: Solder terminal with guard
2: Solder terminal without guard
3: Solder terminal with opposite
side guard
4: Self-standing PC terminal
5: Internationally common pitch
PC terminal
6: Right angle terminal
7: Left angle terminal
8: .110 Quick-connect terminal AV3(FS)
switch
Version
3: Standard 0: Pin plunger
1: Short hinge
lever
2: Hinge lever
3: Long hinge
lever
4: Simulated
roller lever
5: Roller lever Nil: Standard
[11: forward] 0: 0.25 N
(Gold-clad
contact only)
2: 0.49 N
4: 0.98 N
Operating force by
pin plunger, max.
Lever
position
International
standard
Nil: AgNi alloy
61: Gold-clad
triple layer* 3: UL/CSA/
VDE/
SEMKO
Ex. AV 3 2 0 2 3
Type of
switch
Terminals Actuators Contacts
1: Solder terminal with guard
2: Solder terminal without guard
3: Solder terminal with opposite
side guard
4: Self-standing PC terminal
5: Internationally common pitch
PC terminal
6: Right angle terminal
7: Left angle terminal
8: .110 Quick-connect terminal AV3
(FS long
life ver.)
switch
Version
M3: Long life 0: Pin plunger
1: Short hinge
lever
2: Hinge lever
3: Long hinge
lever
4: Simulated
roller lever
5: Roller lever Nil: Standard
[11: forward] 5: 1.47 N
Operating force by
pin plunger, max.
Lever
position
International
standard
Nil: AgNi alloy
61: Gold-clad
triple layer* 3: UL/CSA/
VDE/
SEMKO
Ex. AV M3 2 0 2 3
Type of
switch
Terminals Actuators Contacts
2: Solder terminal
4: PC terminal
8: .110 Quick-connect
terminal AVT3
(FS-T)
switch
Version
T3: Standard 0: Pin plunger
1: Short hinge lever
2: Hinge lever
3: Long hinge lever
4: Simulated roller
lever
5: Roller lever 0: 0.25 N
(Gold-clad
contact only)
2: 0.49 N
4: 0.98 N
Operating force by
pin plunger, max.
Nil: AgNi alloy
(Not applicable
to 0.25 N type)
61: Gold-clad
triple layer*
Agency
standard
3: UL/CSA/
VDE/
SEMKO
Ex. AV T3 2 0 2 3
Lever
position
Nil: Standard
[11: forward]
Type of
switch
Terminals Actuators Contacts
2: Solder terminal
4: PC terminal
8: .110 Quick-connect
terminal AVL3
(FS-T
long life
ver.)
switch
Version
L3: Long life 0: Pin plunger
1: Short hinge lever
2: Hinge lever
3: Long hinge lever
4: Simulated roller
lever
5: Roller lever 5: 1.47 N
Operating force by
pin plunger, max.
Nil: AgNi alloy
(Not applicable
to 0.25 N type)
61: Gold-clad
triple layer*
Agency
standard
3: UL/CSA/
VDE/
SEMKO
Ex. AV L3 2 0 2 3
Lever
position
Nil: Standard
[11: forward]
Au CuNi AgNi
