AV3,AVM3/AVT3,AVL3
Long hinge lever
NC
NO
C
13.1 ±0.4
3.5 max.
4.0
12.2
(O.P.)
(P.T.)
±1.3
8.8
(O.P.)
±1.2
Pretravel, Max. mm 3.5
Movement differential, Max. mm 1.0
Overtravel, Min. mm 1.6
Operating
position
Distance from mounting
hole, mm
8.8 ±1.2
Distance from standoff,
mm
12.2 ±1.3
mm General tolerance: ±0.25
Simulated roller lever
R2.5
NC
NO
C
6.3 ±0.4
2.8 max.
4.0 (P.T.)
15.05
(O.P.)
±0.9
11.65
(O.P.)
±0.8
Pretravel, Max. mm 2.8
Movement differential, Max. mm 0.8
Overtravel, Min. mm 1.2
Operating
position
Distance from mounting
hole, mm
11.65 ±0.8
Distance from standoff,
mm
15.05 ±0.9
Roller lever
3.2
5.0 dia.
NC
NO
C
5.15 ±0.4 2.5 max.
17.9
(O.P.)
(P.T.)
±0.9
14.5
(O.P.)
±0.8
Pretravel, Max. mm 2.5
Movement differential, Max. mm 0.5
Overtravel, Min. mm 0.8
Operating
position
Distance from mounting
hole, mm
14.5 ±0.8
Distance from standoff,
mm
17.9 ±0.9
1-(5) Internationally common pitch PC terminal
(P.T.)
0.6max. 4.0
2.4
1.3
(4.0)
3.2
7.4
6-C0.3
7.62 ±0.1
19.8 ±0.3
7.62 ±0.1
(O.P.)
8.4
±0.3
(O.P.)
11.8
±0.4
3.4 ±0.15
0.5
PC board pattern
3-1.5 ±0.05 dia.
7.62 ±0.1 7.62±0.1
1-(6) Right angle terminal
(P.T.)
0.6max. 4.0
2.4
(4.0)
(2.8)
7.62 ±0.1
19.8 ±0.3
7.62 ±0.1
(O.P.)
8.4
±0.3
3.4 ±0.15
6.4
0.5
R0.5
5.08 ±0.2
PC board pattern
3-1.5 ±0.05 dia.
7.62 ±0.1 7.62±0.1
