Panasonic AV(FS-FS-T) - Manual (Page 12)

AV3,AVM3/AVT3,AVL3
Hinge lever
NO
NC C
7.15 ±0.4
2.8 max.
4.0 (P.T.)
8.8
(O.P.)
±0.8
12.85
Pretravel, Max. mm 2.8
Movement differential, Max. mm 0.8
Overtravel, Min. mm 1.2
Operating
position
Distance from mounting
hole, mm
8.8 ±0.8
Distance from standoff,
mm
12.1 ±0.9
mm General tolerance: ±0.25
Long hinge lever
NO
NC C
13.1 ±0.4 3.5 max. 4.0
(P.T.)
8.8
(O.P.)
±1.2
Pretravel, Max. mm 3.5
Movement differential, Max. mm 1.0
Overtravel, Min. mm 1.6
Operating
position
Distance from mounting
hole, mm
8.8 ±1.2
Distance from standoff,
mm
12.1 ±1.3
Simulated roller lever
NO
NC C
R2.5
6.3 ±0.4 2.8 max.
4.0 (P.T.)
11.65
(O.P.)
±0.8
12.85
Pretravel, Max. mm 2.8
Movement differential, Max. mm 0.8
Overtravel, Min. mm 1.2
Operating
position
Distance from mounting
hole, mm
11.65 ±0.8
Distance from standoff,
mm
14.95 ±0.9
Roller lever
NO
NC C
3.2
5.0 dia.
5.15 ±0.4
2.5 max.
(P.T.)
14.5
(O.P.)
±0.8
Pretravel, Max. mm 2.5
Movement differential, Max. mm 0.5
Overtravel, Min. mm 0.8
Operating
position
Distance from mounting
hole, mm
14.5 ±0.8
Distance from standoff,
mm
17.8 ±0.9
2-(2) Solder terminal
16.1
8.8
NO
NC C
6.4
1.8 dia.
6-C 0.3
(3.9)
2.8 ±0.2
6.4
4.0
1.5
±0.2
0.6 max.
2.4
9.5
7.6
0.5
8.4
(P.T.)
6.7 7.7
3.3
-0.05
+0.1 2.4
2.5
±0.3
±0.1
±0.1
(O.P.)
±0.3
2.4 dia. +0.1
-0.05
19.8 ±0.3
As for the dimensions of lever types, dimensions other than terminals are same as self-standing solder terminal.
