Setup Command Menu

73

Model 3202 Getting Started Guide

5 • Console and Telnet configuration

Setup Command Menu

The setup command menu lists commands for initially configuring the Model 3202. Move the cursor “ >>” to
setup in the main menu and press Enter.

When you enter the setup command, the following menu displays:

G.SHDSL

The g.shdsl command menu lists commands for setting up the DSL port. Move the cursor “ >>” to g.shdsl in
the setup menu and press Enter. The following menu displays:

Table 18

shows the options available within the g.shdsl command menu:

>>

g.shdsl

Configure g.shdsl parameters

lan

Configure LAN interface profile

vlan

Configure virtual LAN parameters

qos

Configure Quality of Service parameters

rate

Configure Rate Control parameters

mgmt

Configure management interface profile

dhcp

Configure DHCP parameters

dns_proxy Configure DNS proxy parameters
hostname

Configure local host name

default

Restore factory default settings

>>

mode

Configure g.shdsl mode

link

Configure g.shdsl link

annex

Configure g.shdsl annex type

tcpam

Configure g.shdsl TCPAM type

maxMainRate Configure g.shdsl max main data rate
snrMargin

Configure g.shdsl SNR margin

lineProbe

Configure g.shdsl line probe

clear

Clear current CRC error count

Table 18. G.SHDSL Options

Menu

Options

Mode

STU-C STU-R

Link Type

2-wire 4-wire 8-wire

Annex

AF BG

TCPAM

Auto TCPAM-16 TCPAM-32 TCPAM-64

Max Main Rate (3–177)
SNR Margin

(-10–21)

Line Probe

Disable Enable
