Distance charts 25
Model 3202 Getting Started Guide 2 • Applications overview
Distance Chart Model 3202/8W (8 Wire/4 Pair)
Table 6. Distance Chart Model 3202/8W (8 Wire/4 Pair)
DSL Line Rate 26 AWG/0.4mm 24 AWG/0.5mm 22 AWG/0.65mm
N kbps kft km kft km kft km
12 768 21.5 6.6 27.2 8.3 34.8 10.6
16 1024 19.5 5.9 24.7 7.5 31.5 9.6
32 2048 17.5 5.3 22.1 6.7 28.3 8.6
48 3072 16.5 5 20.9 6.4 26.7 8.1
64 4096 16 4.9 20.2 6.2 25.9 7.9
80 5120 15 4.6 19 5.8 24.3 7.4
96 6144 14.5 4.4 18.3 5.6 23.5 7.2
128 8192 13.5 4.1 17.1 5.2 21.8 6.6
144 9216 13 4 16.4 5 21 6.4
240 15360 10 3 12.6 3.8 16.2 4.9
288 18432 9.5 2.9 12 3.7 15.4 4.7
356 22784 8.5 2.6 10.8 3.3 13.8 4.2
