Distance charts
24
Model 3202 Getting Started Guide
2 • Applications overview
Distance charts
Distance Chart 3200 Series (Per Wire Pair)
Distance Chart Model 3202/4W (4 Wire/2 Pair)
Table 4. Distance Chart 3202 Series (Per Wire Pair)
DSL Line Rate
26 AWG/0.4mm
24 AWG/0.5mm
22 AWG/0.65mm
N
kbps
kft
km
kft
km
kft
km
3
192
21.5
6.6
27.2
8.3
34.8
10.6
4
256
19.5
5.9
24.7
7.5
31.5
9.6
8
512
17.5
5.3
22.1
6.7
28.3
8.6
12
768
16.5
5
20.9
6.4
26.7
8.1
16
1024
16
4.9
20.2
6.2
25.9
7.9
20
1280
15
4.6
19
5.8
24.3
7.4
24
1536
14.5
4.4
18.3
5.6
23.5
7.2
32
2048
13.5
4.1
17.1
5.2
21.8
6.6
36
2304
13
4
16.4
5
21
6.4
60
3840
10
3
12.6
3.8
16.2
4.9
72
4608
9.5
2.9
12
3.7
15.4
4.7
89
5696
8.5
2.6
10.8
3.3
13.8
4.2
Table 5. Distance Chart Model 3202/4W (4 Wire/2 Pair)
DSL Line Rate
26 AWG/0.4mm
24 AWG/0.5mm
22 AWG/0.65mm
N
kbps
kft
km
kft
km
kft
km
6
512
19.5
5.9
24.7
7.5
31.5
9.6
8
512
19.5
5.9
24.7
7.5
31.5
9.6
16
1024
17.5
5.3
22.1
6.7
28.3
8.6
24
1536
16.5
5
20.9
6.4
26.7
8.1
32
2048
16
4.9
20.2
6.2
25.9
7.9
40
2560
15
4.6
19
5.8
24.3
7.4
48
3072
14.5
4.4
18.3
5.6
23.5
7.2
64
4096
13.5
4.1
17.1
5.2
21.8
6.6
72
4608
13
4
16.4
5
21
6.4
120
7680
10
3
12.6
3.8
16.2
4.9
144
9216
9.5
2.9
12
3.7
15.4
4.7
178
11392
8.5
2.6
10.8
3.3
13.8
4.2
