21
■ Setup Menus for PS • Data
● Communication setup (PS • Data)
Communication parameters for a PS • Data protocol system
are set in this menu.
1. Hold down the SETUP button for 2 seconds to open the
setup menu.
2. Move the cursor to COMMUNICATION , then press
SET. The communication setup appears.
8 UNIT ADDRESS
1. Move the cursor to UNIT ADDRESS, then specify a
number with the [–] or [+] button. The default setting is
1.
Available numbers: 1-99
Note: This setting takes effect only when the UNIT
switch is set to 0 on the front panel.
BAUD RATE
1. Move the cursor to BAUD RATE, then specify a rate
with the [–] or [+] button. The default setting is 9 600.
Available rates (bit per second): 19 200, 9 600,
4 800, 2 400
DATA BIT
1. Move the cursor to DATA BIT, then specify a bit length
with the [–] or [+] button. The default setting is 8.
Available bit length: 7, 8
PARITY
1. Move the cursor to PARITY CHECK, then specify a
check mode with the [–] or [+] button. The default set-
ting is NONE.
Available check modes: NONE, EVEN, ODD
STOP BIT
1. Move the cursor to STOP BIT, then specify a bit length
with the [–] or [+] button. The default setting is 1.
Available bit length: 1, 2
WAIT TIME
The unit will retransmit data when there is no response dur-
ing the specified wait time.
1. Move the cursor to WAIT TIME, then specify a time with
the [–] or [+] button. The default setting is OFF for not
resending.
Available wait times (ms): OFF, 100, 200, 400,
1 000
2. Press ESC to return to the WJ-MP204C SETUP MENU.
● System setup (PS • Data)
Parameters related to alarm, sync, and remote functions
are set in this menu for a PS
• Data protocol system.
The SYSTEM menu is displayed when you select it in the
WJ-MP204C SETUP MENU.
COMMUNICATION
UNIT ADDRESS 1
BAUD RATE 9600
DATA BIT 8
PARITY CHECK NONE
STOP BIT 1
WAIT TIME OFF
SYSTEM
ALARM MODE ON
COMP/VD2/DATA
VS/VD INPUT VD
CAMERA CONFIG
DAISY MODE ON
TERMINAL ALARM
WJ-MP204C SETUP MENUX.XX
COMMUNICATION
SYSTEM
