57
■ To Access Setup Menus
There are fourteen setup menus to adapt the WJ-HD200 to
your requirements.
1. On the Main Control Panel , click the [SETUP MENU]
button. The setup menu opens.
2. Click the buttons to open the respective windows.
TIMER SETUP: Specifies the schedule and parameters
for timer recordings.
REC SETUP: Specifies the parameters for manual and
alarm recordings.
EXT REC SETUP: Selects optional parameters to be
applied to the recording while the externally con-
nected switch to EXT REC terminal turns on.
DISPLAY SETUP: Specifies time-and-date and other
displays of status information.
SYSTEM SETUP: Specifies password-protection, and
simultaneous REC&PLAY.
ALARM SETUP: Specifies alarm-related monitoring
mode, and VMD (video motion detector) mode.
COMMUNICATION SETUP: Specifies parameters for
serial and network communications.
SWITCHER SETUP: Specifies sequence and multi-split
patterns.
SYSTEM INFORMATION: Displays various system
information.
WJ-HD200 SETUP
USER SETUP: Specifies users, passwords, and
access levels.
HOST SETUP: Specifies hosts and access levels.
FTP SETUP: Specifies parameters on transmitting files.
MAIL SETUP: Specifies senders, and receivers.
NETWORK VIDEO SETUP: Specifies application soft-
ware for video translation, and sequence steps.
3. To return to the MAIN CONTROL PANEL , click the
[Main Control Panel] tub or [BACK] button on the win-
dow.
■ Timer Setup TIMER SETUP
● TIMER REC
OFF: Runs recording when manually operated, not
using any timer. Recording parameters are speci-
fied in the REC SETUP window.
INT: Runs recording with the programmed picture qual-
ity at the time zone scheduled on the internal timer.
EXT: Runs recording when the externally connected
timer switch turns on and supplies the power to the
recorder (Power-on recording). Recording parame-
ters are specified in the REC SETUP window.
