56
■ Main Page and Control Panel
Start your PC WWW browser. Type http://192.168.0.10/ (or
the IP Address set for WJ-HD200) / in the URL (
U niform
R esource L ocators) space.
The browser displays the MAIN CONTROL PANEL of the
WJ-HD200 homepage as shown in the figure.
Notes:
• Specify “http//:192.168.0.10/” when a client PC is con-
nected alone.
• Specify “http//: (IP address previously set for the WJ-
HD200)/” such as a LAN connection.
• A maximum of four PC's are accessible to the recorder
at a time.
About Picture Quality
Picture quality transferred via the network depends on the recorder's status as follows.
Recorder Status Displayed Quality
Timer recording Preset recording quality
Pre-alarm period Preset alarm recording quality
Except pre-alarm period Preset manual recording quality
Playback Recorded quality on the disk
