8
OneTouch ® Ultra ®
Test Strips
The OneTouch ® Ultra ® System measures the amount of glucose in whole
blood. Blood is applied in the TOP EDGE of the OneTouch ® Ultra ® Test
Strip and is automatically drawn into the reaction cell where the
reaction takes place.
CONTACT BARS
Insert this end of the test strip,
contact bars facing up, into the
meter. Push it all the way in until
it will go no further.
TOP EDGE
Apply a drop of blood to the
narrow channel here in the top
edge of the test strip.
CONFIRMATION WINDOW
Check here to confirm if enough
blood has been applied.
