7. Push the internal speaker outward through the hole 1 to disengage it from the two metal tabs on the
chassis. Then, slide the internal speaker to the right to remove it from the chassis.
Figure 96. Removing the internal speaker
8. Align the new internal speaker with the two metal clips on the chassis, and then slide the speaker
as shown until it snaps into position.
Chapter 9 . Replacing FRUs (Machine Types: 4466, 4471, 4474, 4477, 4480, 4485, 4496, 4498, 4503, 4512, 4514,
4518, 4554, 7005, 7023, 7033, 7035, 7072, 7079, and 7177.) 157
