Page 151
About the Reports
Printing Reports
9 - 9
TX Result Report
1. Page number : 1 ~ 5 pages
2.
Output method: Print out automatically or set by user setting after communication or use Report utilities
manual printing.
3. Report items:
1 SESSION ----------------------------------- Session number
2 FUNCTION ---------------------------------Function name as below:
1.TX 2. BROADCAST 3. POLLING TX 4. TIMER TX 5. RX
6. POLLING RX 7. MAILBOX TX 8. MAILBOX RX 9. RELAY INIT.
10. RELAY REP.TX
3 No.--------------------------------------------- Location number sequence
4 DESTINATION STATION --------------- Destination name/telephone number
5 DATE/TIME -------------------------------- Communication date/time
6 PAGE ----------------------------------------- Total page number
7 DURATION --------------------------------- Communication interval
8 MODE ---------------------------------------- ECM mode or G3 mode
9 RESULT -------------------------------------- Communication result for each tries
4. Print out format
ADF -------------- Report without image appended at the report page.
MEMORY ------ Print 1
st
page at upper half page with vertical reduction followed by reports.
(Please reference Memory Image Print
1. TX COMPLETELY TO SIGNLE LOCATION
NAME :JONES
TEL:886 3 4733507
DATE:APR.10.2000 12:00
SESSIO
N
FUNCTIO
N
No.
DESTINATION
STATION
DATE
TIME
PAGE
DURATION
MODE
RESULT
0001
TX
001
JONES TAIPEI
03 4733111
APR.18
20:02
003
00h02min
21s
ECM
OK
(1)
(2)
(3)
(4)
(5)
(6)
(7)
(8)
(9)
