Communication Interfaces
91
Table 15 shows the various groups, the settings contained within and the type of value it requires.
Table 15
Group settings and values
Group Item: Description Value Type Value Notes
Group 1:
System
Ratings
1 Input Volts (PDU) Integer Set per system spec.
2 Volts Integer Set per system spec.
3 Current Integer Set per system spec.
4 Frequency Scaled Desired freq. x 10 (600 = 60 Hz)
Group 2:
System
Settings
1 Language Enumeration [Not supported at this time]
2 System Model Number String 14 Character max.
3 System ID Number String 8 Character max.
4 System Tag Number String 8 Character max.
5 System Order Number String 8 Character max.
6 Options_1 Bitpacked 14 Character max.
7 Autodial Primary Line String 20 Character max.
8 Autodial Secondary Line String 20 Character max.
9 Autodial Pager Number String 20 Character max.
10 Autodial Pager PIN String 10 Character max.
11 Modem Init String String 20 Character max.
12 Modem Baud Rate Enumeration 0 = 2400, 1 = 9600, & 2 = 19200 bps
13 Modem LGS Check - Day Bitpacked
14 Modem LGS Check - Time Bitpacked
15 Comms Options 1 Bitpacked See section 12.1.3.
16 Comms Options 2 Bitpacked See section 12.1.3.
Group 3:
User
Settings
1 SRC1 Fast Undervoltage Setpoint Integer In % of nominal below nominal
2 SRC1 Slow Undervoltage Setpoint Integer In % of nominal below nominal
3 SRC1 Slow Undervoltage Detect Delay Integer In number of lines cycles
4 SRC1 Overvoltage Setpoint Integer In % of nominal above nominal
5 SRC1 Overvoltage Detect Delay Integer In 1/4 lines cycles
6 SRC1 I peak Transfer Setpoint Integer x 10
7 SRC2 Fast Undervoltage Setpoint Integer In % of nominal below nominal
8 SRC2 Slow Undervoltage Setpoint Integer In % of nominal below nominal
9 SRC2 Slow Undervoltage Detect Delay Integer In number of lines cycles
10 SRC2 Overvoltage Setpoint Integer In % of nominal above nominal
11 SRC2 Overvoltage Detect Delay Integer In 1/4 lines cycles
12 SRC2 I peak Transfer Setpoint Integer x 10
13 Max. Transfer Phase Angle Integer In degrees
14 Output Frequency Deviation Integer Freq. in Hz x 10
15 ReTransfer Delay Time Integer In seconds
16 Horn Volume Integer Range: 1-10
17 Critical Option Enabling Bitpacked See section 12.1.3.
18 Non-Critical Option Enabling Bitpacked See section 12.1.3.
Group 4:
Event
Mask
Settings
1 to 63 Event Mask settings for faults Event Mask See section 12.1.3.
64 to 143 Event Mask settings for alarms Event Mask See section 12.1.3.
