Power and Control Wiring
12
4.5
Power Supply
The STS2/PDU is supplied with redundant power supplies that are designed to operate from a voltage
range of 200V to 600V. The unit is set at the factory to match the nameplate voltage. Field adjust-
ments are not necessary. If the unit needs to operate at a voltage other than what is listed on the
nameplate, contact Liebert Global Services or your local Liebert representative. Table 6 provides
transformer tap information.
Table 6
Terminal block 1 and terminal block 2 wire connections
Voltage
Connect
Connect
Jumper Between
F1 TB1-XX
F2 TB1-YY
F3 TB2-XX
F4 TB2-YY
200
1
9
1
9
1-7
220
2
12
2
12
6-8
380
1
8
1
8
2-7
415
1
10
1
10
4-7
600
1
12
1
12
6-7
208
1
10
1
10
1-7
240
1
11
1
11
1-7
400
1
9
1
9
3-7
480
1
11
1
11
5-7
!
CAUTION
Using Table 6, ensure that the wiring for the control transformers matches the input voltage
for the unit.
Improper wiring could result in blown fuses.
