Installation & Operation Manual
45
Access modes
Modes of operation
There are three modes of operation: 1) Off, 2) Pool, and
3) Spa. The factory default mode is Off.
Off mode
When in Off Mode the control will display CONTROL OFF
and does not monitor any of the inputs.
Status Display Screens
Display shows: Description
Control: OFF The control module has been placed in the Off Mode.
Pool: Standby The unit has not received a call for heat.
Pool Temp = ***°F Indicates the current inlet water temperature.
Pool Mode Prepurge
A call for heat has been initiated. The blower has been powered and
the air pressure switch has closed. The prepurge period is 15
seconds.
Pool Mode Ignition
After the prepurge period, the unit has begun a 5 second spark
period to light the main burners.
Pool: Heating The burners have fired and the flame has been detected.
Standby
Remote is active and has either satisfied the set point or there is no
call for heat from the remote.
Setup menu
Additional features can be accessed and adjusted through the
Setup Menu. Please reference the EnergyRite Service Manual
for a detailed description of the Setup Menu.
Service menu
Temperature rise and data logging information can be accessed
from the service menu. Please reference the EnergyRite Service
Manual for a detailed description of the Service Menu.
10
Operating information
(continued)
