Table 7-5. Connect Mode Options
Connect Mode Option
7
6
5
4
3
2
1
0
a) Incoming Connection
Never accept incoming
0
0
0
Accept
with
DTR
Active
0
1
0
Always
Accept
1
1
0
b) Response
Nothing
(quiet)
0
Character response (C=connect,
D=disconnect, N=unreachable)
1
c) Active Startup
No active startup
0
0
0
0
With any character
0
0
0
1
With DTR Active
0
0
1
0
With a specific start character
0
0
1
1
Manual connection
0
1
0
0
Autostart
0
1
0
1
Hostlist
0 0 1 0
d) Datagram Type
Directed UDP
1
1
0
0
e) Modem Mode
No Echo
0
0
1
1
Data Echo & Modem Response
(Numeric)
0
1
1
1
1
Data Echo & Modem Response
(Verbose)
0
1
1
1
0
Modem Response Only (Numeric)
0
0
1
1
1
1
Modem Response Only (Verbose)
0
0
1
1
1
0
