4: Configuration Using Web Manager
UDS2100 User Guide 31
2. In the available fields, enter or modify the following information:
Connect Protocol
Protocol From the drop-down menu, select TCP.
Connect Mode: Passive Connection
Accept Incoming Select Yes to accept incoming connections. The default
setting is Yes.
Password Required Determines whether a password is required for an
incoming passive connection. This field is not available
when a password is set for Telnet mode. The default
setting is No.
Password If Password Required was set to Yes, enter the password
for passive connections.
Connect Mode: Active Connection
Active Connect Select None (default) to disable Active Connect.
Otherwise, indicate the connection type from the drop-
down list:
With Any Character: Attempts to connect when any
character is received from the serial port.
With Active Mdm Ctrl In: Accepts external
connection requests only when the
modem_control_in
input is asserted.
With Start Character: Attempts to connect when it
receives a specific start character from the serial
port. The default start character is carriage return.
Manual Connection: Attempts to connect when
directed by a command string received from the
serial port.
Auto Start: Automatically connects to the remote IP
address and port after booting up.
Start Character If Active Connect is set to With Start Character, enter the
start character in this field. The default setting is 0D.
Modem Mode Indicates the on-screen response type when in Modem
Mode (if Modem Mode is enabled). The default setting is
None.
Endpoint Configuration
Local Port Enter the local port number.
Auto increment for
active connect Select to auto-increment the local port number for new
outgoing connections. The range of auto-incremented
port numbers is 50,000 to 59,999 and loops back to the
beginning when the maximum range is reached. Disabled
