4: Configuration Using Web Manager
UDS2100 User Guide 28
Figure 4-5. Channel Serial Settings
2. In the available fields, enter the following information:
Channel 1
Disable Serial Port When selected, disables communication through the
serial port. The serial port is enabled by default.
Note: This feature is not available on single port device
servers, since it can only be applied to channel 2.
Port Settings
Protocol From the drop-down menu, select the protocol type for
the selected channel. The default setting is RS232.
Flow Control Flow control manages data flow between devices in a
network to ensure it is processed efficiently. Too much
data arriving before a device is prepared to manage it
causes lost or retransmitted data. None is the default.
Baud Rate The unit and attached serial device, such as a modem,
must agree on a speed or baud rate to use for the serial
connection. Valid baud rates are 300, 600, 1200, 2400,
4800, 9600 (default), 19200, 38400, 57600, 115200, 230400,
460800, and 921600 baud. The default setting is 9600.
Data Bits Indicates the number of bits in a transmitted data
package. The default setting is 8.
Parity Checks for the parity bit. The default setting is None.
