Lantronix UDS2100 - Manual (Page 30)

4: Configuration Using Web Manager
UDS2100 User Guide 30
Flush Output Buffer (Network to Serial)
With Active Connect Select Yes to clear the output buffer with a connection
that is initiated from the device to the network. The default
setting is No.
With Passive Connect Select Yes to clear the output buffer with a connection
initiated from the network to the device. The default
setting is No.
At Time of Disconnect Select Yes to clear the output buffer when the network
connection to or from the device is disconnected. The
default setting is No.
3. When you are finished, click the OK button.
4. On the main menu, click Apply Settings.
Connection Settings - TCP
To configure a channel’s TCP settings :
1. On the main menu, click Connection. The Connection Settings window for the
channel displays.
Figure 4-6. TCP Connection Settings
