Installation and

Service Manual

37

Radiant Floor and Snow Melt
Heating Systems

This type of heating boiler application operates in a low
temperature range which requires a boiler bypass as described
under Low Temperature Return Water Systems. A non-metallic
rubber or plastic tubing installed in a radiant (in floor) system
must have an oxygen barrier to prevent oxygen from entering
the system through the walls of the installed tubing. Excessive
oxygen absorption into the system will result in an accelerated
rate of corrosion causing a sludge buildup. This excessive
corrosion will also damage the boiler and system components.
Sludge formed as the result of excessive oxygen in the system
can restrict water flow resulting in a premature boiler failure.
Any boiler damage due to excessive oxygenation is non-
warrantable.

ΔT

ΔT

ΔT

ΔT

10ºF

20ºF

30ºF

40ºF

Input

Output

GPM FT. HD

GPM

FT.HD

GPM FT.HD

GPM

FT.HD

399,999

339,999

68

7.4

34

2.4

23

1.1

17

0.6

500,000

425,000

--

--

42

4.1

28

1.6

21

0.7

650,000

617,500

--

--

55

5.2

37

3.0

28

1.6

750,000

712,500

--

--

63*

7.2

42

4.1

32

2.3

990,000

841,500

--

--

83

5.4

55

2.6

42

1.5

1,260,000

1,071,000

--

--

107*

13

71

4.4

53

2.7

1,440,000

1,224,000

--

--

--

--

81

6.3

61

3.8

1,800,000

1,530,000

--

--

--

--

102*

11.8

76

6.6

2,070,000

1,759,500

--

--

-

--

--

--

--

87

9.0

*Requires Cupro-Nickel heat exchanger.

TABLE-P

System Temperature Rise Chart Based on Btu/hr Input

*

ƽ

CAUTION: The maximum flow rate for models 399,999 - 750,000 Btu/hr is 55 GPM and 90 GPM on

models 990,000 - 2,070,000 Btu/hr. Do not exceed the maximum flow rate of the heating boiler.

If higher flow rates are required through the boiler, an optional Cupro-Nickel heat exchanger is available.
When using a Cupro-Nickel heat exchanger, GPM can be increased by 30 percent. Consult the factory
for specific application requirements.
