TK-260G/270G

40

ADJUSTMENT

Adjustment points TX-RX unit (X57-587)
Component side view

Foil Side View

VR1 : Frequency adjustment

TC1 : Transmit lock voltage adjustment
TC2 : Receive lock voltage adjustment
L305:
L306:

Band-pass filter waveform adjustment

L307:
BPF : Band-pass filter test point
CV(LV) : Lock voltage adjustment terminal.

Fig. 2 Adjustment points

}

MIC

MIC

SP

IC14

C13

BPF

CN3

ANT

VR1

IC12

LV

CV

L307

L306

L305

TC1

TC2

Battery terminal

BPF

ANT

MIC

SP
