TK-260G/270G
PARTS LIST
24
Parts No. Description Address
New
parts
Destination Destination
TK-260G/270G
Ref. No. Parts No. Description Address
New
parts
* New Parts. indicates safety critical components.
Parts without Parts No. are not supplied.
Les articles non mentionnes dans le Parts No. ne sont pas fournis.
Teile ohne Parts No. werden nicht geliefert.
TK-260G/270G
!
L: Scandinavia K: USA P: Canada
Y: PX (Far East, Hawaii) T: England E: Europe
Y: AAFES (Europe) X: Australia M: Other Areas
Ref. No.
260G : TK-260G (K),(M)
270G : TK-270G (K),(M)
M : TK-260G(M),TK-270G(M)
K : TK-260G(K),TK-270G(K)
1 1C * A02-2385-23 CABINET ASSY 270G
2 1A * A02-2391-23 CABINET ASSY 260G
3 3B,3D * A82-0036-02 REAR PANEL
4 2E B09-0351-03 CAP(SP/MIC)
5 2D B11-1220-03 ILLUMINATION GUIDE
6 2D * B38-0820-05 LCD 270G
7 2F B46-0470-00 WARRANTY CARD K
8 2F * B62-1113-00 INSTRUCTION MANUAL 270G
9 2F * B62-1129-00 INSTRUCTION MANUAL 260G
10 1B * D32-0423-05 STOPPER 260G
11 3B,3D E04-0413-05 RF COAXIAL RECEPTACLE(SMA)
12 3A,3C E23-1006-04 RELAY TERMINAL(BATT -)
13 2A,2D * E23-1125-14 RELAY TERMINAL(BATT +)
14 2D * E29-1177-04 INTER CONNECTOR(LCD) 270G
15 2C * E37-0805-05 FLAT CABLE(TX/RX-DISP) 270G
16 2B,1D * E37-0829-05 SPEAKER LEAD ASSY
17 3A,3C * E37-0830-05 FLAT CABLE(PTT)
18 2A,2D * F10-2302-04 SHIELDING COVER(POWER MODULE)
19 2A,2C * F10-2304-03 SHIELDING COVER(TX/RX UNIT)
20 2C * F20-3307-04 INSULATING SHEET(TX/RX UNIT) 270G
21 2C * F20-3308-04 INSULATING SHEET(TX/RX UNIT) 270G
22 1A,1C G01-0881-04 COIL SPRING(BATT RELEASE)
23 1D * G10-1232-04 FIBROUS SHEET(SPEAKER) 270G
24 1A * G10-1233-04 FIBROUS SHEET(SPEAKER) 260G
25 3B,3D * G13-1744-14 CUSHION(CHASSIS-BATT)
26 3A,3D * G53-0881-02 PACKING(SIDE)
27 1D * G53-0882-03 PACKING(SPEAKER/ECM) 270G
28 2A,2D * G53-0883-04 PACKING(BATT TERMINAL)
29 1B * G53-0884-04 PACKING(ECM) 260G
30 1A * G53-0885-04 PACKING(SPEAKER) 260G
31 1A,1C * G53-0891-04 PACKING(PTT KNOB)
32 1E,2F H12-1487-02 PACKING FIXTURE
33 1F H25-0085-04 PROTECTION BAG (100/200/0.07)
34 2E H25-2012-04 PROTECTION BAG (75/100/0.08)
35 3F * H52-1413-02 ITEM CARTON CASE 270G
36 3F * H52-1417-02 ITEM CARTON CASE 260G
37 1A,1C J19-1572-04 HOLDER(BATT RELEASE)
38 2D * J19-5352-03 HOLDER(VOL/ENC) 270G
39 2A,2D * J19-5353-14 HOLDER(BATT TERMINAL)
40 2B * J19-5355-03 HOLDER(VOL/CHANNEL SW) 260G
41 2E J21-4493-04 SP/MIC HOLDER
42 2D * J21-8377-03 LCD HOLDER 270G
43 1D * J21-8378-04 SPEAKER FIXTURE 270G
44 2A * J21-8381-14 SPEAKER FIXTURE 260G
45 2E J29-0624-03 BELT HOOK
46 2C * J32-0925-04 HEXAGON BOSS 270G
47 1C * K29-5330-02 KEY TOP(DTMF) 270G
48 1D * K29-5331-03 KNOB(ENCODER) 270G
49 1B,1D * K29-5332-03 KNOB(VOLUME)
50 1A,1C * K29-5333-13 BUTTON KNOB(MONI/LAMP)
51 1A,1C * K29-5334-13 BUTTON KNOB(PTT)
52 1A,1C K29-5337-03 LEVER KNOB(BATT RELEASE)
53 1B * K29-5341-03 KNOB(CHANNEL SELCTOR) 260G
A 3B,3D N09-2319-05 BINDING HEAD SCREW
B 2A,2D * N09-2331-05 SPECIAL SCREW
C 1B,1D N14-0582-14 CIRCULAR NUT
D 1B,1D N14-0583-04 CIRCULAR NUT
E 1B * N14-0588-04 CIRCULAR NUT 260G
F 3A,3C N30-2606-46 PAN HEAD MACHINE SCREW
G 2A N30-3004-46 PAN HEAD MACHINE SCREW 260G
H 2C N39-2030-46 PAN HEAD MACHINE SCREW 270G
I 2A,2D * N67-2005-46 PAN HEAD SEMS SCREW W
J 3A,3C * N78-2045-46 PAN HEAD TAPTITE SCREW
K 3A,3C * N79-2030-46 PAN HEAD TAPTITE SCREW
L 2A,2C,2D N83-2005-46 PAN HEAD TAPTITE SCREW
M 2E * N99-2012-05 SCREW SET
VR2 - * R31-0628-15 VARIABLE RESISTOR
S1 - * S60-0413-05 ROTARY SWITCH 260G
SP 1D T07-0326-05 SPEAKER 270G
SP 2A T07-0327-05 SPEAKER 260G
ANT - T90-0679-05 HELICAL ANTENNA M
S1 - * W02-1969-05 ENCODER 270G
DISPLAY UNIT (X54-3250-10) (TK-270G only)
D506 B30-2210-05 LED(LCD BACK LIGHT)
D508-510 B30-2171-05 LED(KEY BACK LIGHT)
D511 B30-2210-05 LED(LCD BACK LIGHT)
D512-516 B30-2171-05 LED(KEY BACK LIGHT)
C501-509 CC73GCH1H221J CHIP C 220PF J
C513 CK73GB1H102K CHIP C 1000PF K
C515,516 CC73GCH1H101J CHIP C 100PF J
CN501 * E40-6012-05 FLAT CABLE CONNECTOR
L501,502 L92-0138-05 FERRITE CHIP
CP501 R90-0748-05 MULTI-COMP 47K X4
CP502,503 R90-0724-05 MULTI-COMP 1K X4
R501-510 RK73GB1J102J CHIP R 1.0K J 1/16W
R511 R92-1252-05 0 CHIP R 0 OHM
R512 RK73GB1J102J CHIP R 1.0K J 1/16W
R513-515 RK73GB1J103J CHIP R 10K J 1/16W
R516 RK73GB1J473J CHIP R 47K J 1/16W
R517 RK73GB1J103J CHIP R 10K J 1/16W
R518 RK73GB1J471J CHIP R 470 J 1/16W
R519-522 RK73GB1J102J CHIP R 1.0K J 1/16W
R523 RK73GB1J473J CHIP R 47K J 1/16W
R524 RK73GB1J471J CHIP R 470 J 1/16W
D501-504 MA2S111 DIODE
D505 1SS373 DIODE
