Krell Industries MASTER REFERENCE SUBWOOFER User Manual

Page 34

(SECTION THREE: Features continued)

(Operation Keys continued)

32 Unit Keys

Use these keys to assign an ID to each component when multiple subwoofers

are installed in a configuration. For instructions on assigning an ID, see Optional

Configurations, on page 48, for more information.

33 All Key

Use this key to control all subwoofers at once, for example, to mute, power on, or

set preset configurations for all subwoofers in a configuration.

34 Mute Key

Use this key to mute the low-pass (sub) and the high-pass filter output. To unmute,

press the mute key again. To customize the mute key operation, see Optional

Configurations, on page 48.

Filter Selection Keys

35 Section Sub Key

Use this key to access the low-pass (sub) filter parameters for your system. The

filter’s type, frequency, slope, and level can be adjusted. See Steps III and IV, on

pages 36-40, for more information.

36 Section High Key

Use this key to access the high-pass filter parameters for your system. The filter’s

type, frequency, slope, and level can be adjusted. See Steps III and IV, on pages

36-40, for more information.

Menu Keys

37 Menu Key

Use this key to activate the menu system, to customize subwoofer settings. The

front panel display (4) shows

when the menu key is pressed. Use the adjust

up and down keys (43) to scroll through menu selections.

38 Enter Key

Use this key to set a menu selection or to access a submenu selection.
