(SECTION THREE: Features continued)
20
Figure 3
Power
6 Power Switch
7 AC Input Specification
8 IEC Power Connector
Figure 4
Back Panel Remote Connections
9 Krell Link In and Out
10 12 VDC In and Out
11 12 VDC LFE In
12 RC-5 In
13 RS-232
Inputs
14 Left and Right CAST Inputs
15 Left and Right Balanced Inputs
16 Left and Right Single-ended
Inputs
17 LFE CAST Input
18 LFE Balanced Input
19 LFE Single-ended Input
Outputs
20 Left and Right CAST High-pass
Outputs
21 Left and Right Balanced
High-pass Outputs
22 Left and Right Single-ended
High-pass Outputs
23 Left and Right CAST By-pass
Outputs
24 Left and Right Balanced By-pass
Outputs
25 Left and Right Single-ended
By-pass Outputs
Figure 3 Master Reference Subwoofer Back Panel ( Power)
50/60 Hz
MADE IN USA
KRELL INDUSTRIES, INC.
45 CONNAIR ROAD
USA
ORANGE, CT 06477-3650
7
8
6
