(SECTION ONE: About Krell continued)
continued ᮣ
11
Configurations
A method of configuring multiple Krell preamplifiers, amplifiers,
and associated components and synchronizing their stand-by/
operational modes. Using Krell Link in/out connections and
MIDI cables, the remote capabilities of the linked components
are controlled by one component, called the control component.
The linked components respond to stand-by and operational
mode commands from the control component.
Inputs and Outputs
A symmetrical input or output circuit that has equal impedance
from both input terminals to a common ground reference point.
The industry standard for professional and sound recording
installations, balanced connections have 6 dB more gain than
single-ended connections and allow the use of long intercon-
nect cables.
An output that allows you to integrate additional Master Reference
Subwoofers into your system. The input signal of a component
connected to the by-pass output passes directly through the
subwoofer with no modification.
An output that transmits the signal from the high-pass filter of
the programmable electronic crossover to the amplifiers driving
the main left and right loudspeakers.
Note
There is no low-pass (subwoofer) connector on the Master Reference
Subwoofer. The low-pass output is connected directly to the internal
amplifier.
Krell Link
Balanced
By-pass Output
High-pass Output
Definition of Terms
Following are the definitions of key terms used in your owner’s reference manual.
